C3-400 Access Paneli

Access kontrol paneli kapı ve turnikelerde geçişleri kontrol etmek ve kişilere özel yetki atamak için kullanılır.

Access kontrol paneli reader bağlanarak çalışır. Kontrol ünitesi dört kapı kontrol eder. Kart okutulduğunda redaer panele sorgu yapar ve geçiş yetkisine göre geçiş verir.

  • + TEKNİK ÖZELLİKLER

     Number of Doors Controlled

     1 Door

     2 Door

     4 Door

     Number of Readers Supported

     2

     4

     4

     Types of Readers Supported

     26-bit Wiegand, others upon request

     26-bit Wiegand, others upon request

     26-bit Wiegand, others upon request

     Number of Inputs

     2 (Exit Device and Door Status, AUX)

     6 (2 Exit Device, 2 Door Status, 2 AUX)

     12 (4 Exit Device, 4 Door Status, 4 AUX)

     Number of Outputs

     2 (1-From C Relay for Lock and 1-Form C Relay for Aux Output)

     4 (2-From C Relay for Lock and 2-Form C Relay for Aux Output)

     8 (4-Form C Relay for Lock and 4-Form C Relay for Aux Output)

     Number of Doors Controlled

     1 Door

     2 Door

     4 Door

     Number of Readers Supported

     2

     4

     4

     Types of Readers Supported

     26-bit Wiegand, others upon request

     26-bit Wiegand, others upon request

     26-bit Wiegand, others upon request

     Number of Inputs

     2 (Exit Device and Door Status, AUX)

     6 (2 Exit Device, 2 Door Status, 2 AUX)

     12 (4 Exit Device, 4 Door Status, 4 AUX)

     Number of Outputs

     2 (1-From C Relay for Lock and 1-Form C Relay for Aux Output)

     4 (2-From C Relay for Lock and 2-Form C Relay for Aux Output)

     8 (4-Form C Relay for Lock and 4-Form C Relay for Aux Output)

     Card Holders Capacity

     30,000

     30,000

     30,000

     Log Events Capacity

     100,000

     100,000

     100,000

     Weight

     7.4lbs (3.35kg)

     7.5lbs (3.4kg)

     7.8lbs (3.55kg)

     Communication

     TCP/IP and RS-485

     TCP/IP and RS-485

     TCP/IP and RS-485

     Enclosure

     Powder Coated Aluminium

     Powder Coated Aluminium

     Powder Coated Aluminium

     Mounting

     Wall Mount

     Wall Mount

     Wall Mount

     Recommended Power Supply

     12V DC, 1.5A

     12V DC, 1.5A

     12V DC, 1.5A

     Dimensions (Bundle Only)

     15in.×3.15in.×11in.
    380mm(L) X 80mm(W) X 280mm(H)

     15in.×3.15in.×11in.
     380mm(L)×80mm(W)×280mm(H)

     15in.×3.15in.×11in.
     380mm(L)×80mm(W)×280mm(H)

     Dimensions ( Board Only)

     6.3in.×4.17in.
     (160mm×106mm)

     6.3in.×4.17in.
     (160mm×106mm)

     6.3in.×4.17in.
     (160mm×106mm)
